Standard Configuration
- Integral Bed Frame
- Cooling System
- CNC System (Xiankong), 7.5KW Main Motor and Frequency Converter
- Electrical Control System
Optional Configuration
- 2-Station Electric Transmission
- Steady Rest
- CNC System (Inovance, Xiankong, Lyuwei, etc.)
- Direct Pressure Chuck (Hydraulic/Pneumatic)
- Servo Feed Transmission System
- Semi-Enclosed Protective Cover
- 1-Station Electric Turret
- Automatic Lubrication System
Parameter Table
| Item | Unit | NY-2614 |
| NC System | – | Inovance, Xiankong, Lyuwei; KND2000/Guangshu GSK 980TDI (Optional) |
| Maximum Swing Diameter of Bed | mm | 750 |
| Maximum Swing Diameter of Turret | mm | 200 |
| Bed Guide Rail Width | mm | 550 (split-type); 750 (Integrated) |
| X/Z Axis Rapid Traverse Speed | mm/min | 6000/8000 |
| X/Z Axis Rapid Traverse Speed | mm/min | 6000/8000 |
| X/Z Axis Minimum Feed Increment | mm | 0.001/0.001 |
